Back to product catalogue

MENAKA 54 G2

Quick-mounting LED strip system with higher IP 54 protection, ideal for lighting industrial spaces and interiors.

LED Light Electric Diode
Regulace DALI DALI regulation
Elektrický zdroj (EVG) Power Supply
Funkce koridor (CORRIDOR) Corridor function
Distribuce světla (přímá) Light distribution: direct
Integrovaný nouzový modul Integrated emergency module
Montáž přisazením Surface mounting
Montáž zavěšením Suspension mounting
Montáž na hořlavé podklady Mounting on flammable substrates
Stupeň krytí (54) Degree of protection
Zjistit více ikonka Learn more about the product

Specifications

Electrical parameters

Light source LED
Power voltage AC 230 V / 50 Hz
Connection method terminal block
Ballast part electronic driver
Possibility of regulation non-dimmable (not labeled), DALI (DALI), corridor function (EPS-C)
Emergency module NO

Light parameters

Optical system wide beam (C), narrow beam (D), racking aisles (CC)
Light distribution direct
Colour rendering index Ra > 80
Colour temperature 3,000 K / 4,000 K
Service life > 72,000 hrs. (L80B10)

Construction

Luminaire body powder-coated steel sheet
Colour RAL 9003, other RAL (on request)
Surface type gloss
Luminaire cover coated sheet, PMMA optics

Safety

Protection class I
Maximum ambient temperature +5 / +40 °C
Protection of the luminaire's electrical part IP 54
Protection of the luminaire's optical part IP 54
Mounting on normally flammable surfaces YES

Mounting

Method suspension, surface mounted
Recommended height from 3 to 20 m

Accessories

Clips NO
Suspension accessories suspension hook; wire suspension and chain (on request)
Use industrial areas, racking aisles, warehouses

Energy label

Energy label

Files for download

Inquiry form
