MANU SQ

Designed wooden LED luminaire for interiors and architectural projects.

LED Light Electric Diode
Způsob připojení (svorkovnice) Connection method: terminal board
Regulace DALI DALI regulation
Elektrický zdroj (EVG) Power Supply
Funkce koridor (CORRIDOR) Corridor function
Distribuce světla (přímá) Light distribution: direct
Montáž přisazením Surface mounting
Montáž zavěšením Suspension mounting
Montáž na stěnu Wall mounting
Montáž na hořlavé podklady Mounting on flammable substrates
Stupeň krytí (40) Degree of protection
Zjistit více ikonka Learn more about the product

Specifications

Electrical parameters

Light source LED
Power voltage AC 230 V / 50 Hz
Connection method terminal block
Ballast part electronic driver
Possibility of regulation non-dimmable (not labeled), DALI (DALI), corridor function (EPS-C)
Emergency module NO

Light parameters

Optical system diffuser
Light distribution direct
Colour rendering index Ra > 80
Colour temperature 3,000 K / 4,000 K
Service life > 50,000 hrs. (L80B10)

Construction

Luminaire body massive (oak/beek); brushed oak
Luminaire cover opal (DPO)

Safety

Protection class I
Maximum ambient temperature +10 / +30 °C
Protection of the luminaire's electrical part IP 40
Protection of the luminaire's optical part IP 40
Mounting on normally flammable surfaces YES

Mounting

Method suspension
Recommended height max. up to 5 m

Accessories

Clips NO
Suspension accessories wire suspension
Use corridors, commercial spaces, department stores, gallery, offices, restaurants
