HARI

Industrial high-efficiency LED luminaire with a long service life for a wide range of applications.

Regulace DALI DALI regulation
Stupeň krytí (IP65) Degree of protection
Zjistit více ikonka Learn more about the product
Zjistit více ikonka Learn more about the product
HARI

Specifications

Electrical parameters

Light source LED
Power voltage AC 230 V / 50 Hz
Connection method cable out 3 × 1,5 mm2, 1,5 m
cable out 5 × 1,5 mm2, 1,5 m
Gesis (on request)
Possibility of regulation non-dimmable (not labeled), DALI (DALI), corridor function (EPS-C)
Emergency module additional MN emergency module

Light parameters

Optical system wide beam (C), narrow beam (D), racking aisles (O)
Light distribution direct
Colour rendering index Ra > 80
Colour temperature 4,000 K / 5,000 K
Service life > 92,000 hrs. (L80B50)

Construction

Luminaire body aluminium, PC
Colour aluminium + RAL 7045
Surface type gloss
Luminaire cover safety glass

Safety

Protection class I
Maximum ambient temperature -5 / +40 °C
Protection of the luminaire's electrical part IP 65
Protection of the luminaire's optical part IP 65
Mounting on normally flammable surfaces YES

Mounting

Method suspension, surface mounted (it‘s necessary to order a clamp for attachment)
Recommended height from 5 to 20 m

Accessories

Clips NO
Suspension accessories suspension hook; clamp for attachment and chains (on request)
Use industrial areas, racking aisles, warehouses

Energy label

Energy label

Files for download

Eulumdata

Inquiry form
