GERMIN

Disinfection equipment using UVC radiation technology, designed to disinfect air and surfaces.

UVC záření UVC radiation
Zářivková trubice (T8) Fluorescent tube
Způsob připojení (svorkovnice) Connection method: terminal board
Elektrický zdroj (EVG) Power Supply
Distribuce světla (přímá) Light distribution: direct
Montáž přisazením Surface mounting
Stupeň krytí (20) Degree of protection
Zjistit více ikonka Learn more about the product

Specifications

Electrical parameters

Light source T8
Power voltage AC 230 V / 50 Hz
Connection method terminal block
Ballast part electronic driver
Possibility of regulation NO

Light parameters

Radiation 180°
Radiation at 253,7 nm min. UVC radiation at the beginning – 150 μW/cm2 (at a distance of 1 metre)
after 9 000 hrs. – 130 μW/cm2 (at a distance of 1 metre)
Tube life 9,000 hrs.

Construction

Luminaire body stainless steel sheet
Surface type brushed stainless steel

Safety

Protection class I
Maximum ambient temperature +5 / +35 °C
Protection of the luminaire's electrical part IP 20
Protection of the luminaire's optical part IP 20

Mounting

Use apartment, consulting rooms, corridors, sports grounds, waiting rooms

Energy label

Energy label
